How black holes shape the cosmos
Astrophysicists from Heidelberg, Garching, and the USA gained new insights into the formation and evolution of galaxies. They calculated how black holes influence the distribution of dark matter, how heavy elements are produced and distributed throughout the cosmos, and where magnetic fields originate. This was possible by developing and programming a new simulation model for the universe, which created the most extensive simulations of this kind to date. First results of the “IllustrisTNG” project have now been published in three articles in the journal Monthly Notices of the Royal Astronomical Society. These findings should help to answer fundamental questions in cosmology.
Every galaxy harbours a supermassive black hole at its center. A new computer model now shows how these gravity monsters influence the large-scale structure of our universe. The research team includes scientists from the Heidelberg Institute for Theoretical Studies (HITS), Heidelberg University, the Max-Planck-Institutes for Astronomy (MPIA, Heidelberg) and for Astrophysics (MPA, Garching), US universities Harvard and the Massachusetts Institute of Technology (MIT), as well as the Center for Computational Astrophysics in New York. The project, “Illustris–The Next Generation” (IllustrisTNG) is the most complete simulation of its kind to date. Based on the basic laws of physics, the simulation shows how our cosmos evolved since the Big Bang. Adding to the predecessor Illustris project, IllustrisTNG includes some of the physical processes which play a crucial role in this evolution for the very first time in such an extensive simulation.
A realistic universe out of the computer
At its intersection points, the cosmic web of gas and dark matter predicted by IllustrisTNG hosts galaxies quite similar to the shape and size of real galaxies. For the first time, hydrodynamical simulations could directly compute the detailed clustering pattern of galaxies in space. Comparison with observational data - including newest large surveys - demonstrate the high degree of realism of IllustrisTNG. In addition, the simulations predict how the cosmic web changes over time, in particular in relation to the underlying “back bone” of the dark matter cosmos. “It is particularly fascinating that we can accurately predict the influence of supermassive black holes on the distribution of matter out to large scales,” says principal investigator Prof. Volker Springel (HITS, MPA, Heidelberg University). “This is crucial for reliably interpreting forthcoming cosmological measurements.”
The most important transformation in the life cycle of galaxies
In another study, Dr. Dylan Nelson (MPA) was able to demonstrate the important impact of black holes on galaxies. Star-forming galaxies shine brightly in the blue light of their young stars until a sudden evolutionary shift ends the star formation, such that the galaxy becomes dominated by old, red stars, and joins a graveyard full of “red and dead” galaxies. “The only physical entity capable of extinguishing the star formation in our large elliptical galaxies are the supermassive black holes at their centers,” explains Nelson. “The ultrafast outflows of these gravity traps reach velocities up to 10 percent of the speed of light and affect giant stellar systems that are billions of times larger than the comparably small black hole itself.”
Where the stars sparkle: New findings for the structures of galaxies
IllustrisTNG also improves researchers’ understanding of the hierarchical structure formation of galaxies. Theorists argue that small galaxies should form first, and then merge into ever larger objects, driven by the relentless pull of gravity. The numerous galaxy collisions literally tear some galaxies apart and scatter their stars onto wide orbits around the newly created large galaxies, which should give them a faint background glow of stellar light. These predicted pale stellar halos are very difficult to observe due to their low surface brightness, but IllustrisTNG was able to simulate exactly what astronomers should be looking for in their data. “Our predictions can now be systematically checked by observers,” Dr. Annalisa Pillepich (MPIA) points out, who led a further IllustrisTNG study. “This yields a critical test for the theoretical model of hierarchical galaxy formation.”
Astrophysics with a special code and a supercomputer
For the project, the researchers developed a particularly powerful version of their highly parallel moving-mesh code AREPO and used it on the Hazel Hen machine at the High-Performance Computing Center Stuttgart, Germany's fastest mainframe computer, currently ranked nineteenth in the Top500. IllustrisTNG is the largest hydrodynamic simulation project to date for the emergence of cosmic structures. To compute one of the two main simulation runs, over 24,000 processors were used over the course of more than two months to follow the formation of millions of galaxies in a representative region of the universe with nearly one billion light-years on a side. “Thanks to the computing time obtained from the German Gauss Centre for Supercomputing, we have been able to redefine the state of the art in this field,” explains Volker Springel. “The new simulations produced more than 500 terabytes of simulation data. Analyzing this huge mountain of data will keep us busy for years to come, and it promises many exciting new insights into different astrophysical processes."
Original scientific publications:
• V. Springel, R. Pakmor, A. Pillepich, R. Weinberger, D. Nelson, L. Hernquist, M. Vogelsberger, S. Genel, P. Torrey, F. Marinacci, J. Naiman
“First results from the IllustrisTNG simulations: matter and galaxy clustering”, MNRAS, Feb 1st, 2018
• D. Nelson, A. Pillepich, V. Springel, R. Weinberger, L. Hernquist, R. Pakmor, S. Genel, P. Torrey, M. Vogelsberger, G. Kauffmann, F. Marinacci, J. Naiman
“First results from the IllustrisTNG simulations: the galaxy color bimodality”, MNRAS, Feb 1st, 2018
• A. Pillepich, D. Nelson, L. Hernquist, V. Springel, R. Pakmor, P. Torrey, R. Weinberger, S. Genel, J. Naiman, F. Marinacci, M. Vogelsberger
“First results from the IllustrisTNG simulations: the stellar mass content of groups and clusters of galaxies”, MNRAS, Feb 1st, 2018
Web page of the Illustris-TNG project (with additional visualizations and videos)
The AREPO simulation code
Gauss Centre for Supercomputing
Hazel-Hen at the Supercomputing Centre Stuttgart
Press contact HITS:
Dr. Peter Saueressig
Press contact MPIA:
Dr. Markus Pössel
Press contact MPA:
Dr. Hannelore Hämmerle
Prof. Dr. Volker Springel
Heidelberg Institute for Theoretical Studies (HITS) / Heidelberg University / MPA
Dr. Annalisa Pillepich
Max-Planck Institute for Astronomy (MPIA)
Dr. Dylan Nelson
Max-Planck Institut for Astrophysics (MPA)
http://www.tng-project.org/ IllustrisTNG collaboration
http://www.tng-project.org/people/ collaborating researchers and institutions
https://youtu.be/4IIEJlSwuXo Time evolution of the cosmic magnetic field strength.
https://youtu.be/Ed9CC7s4NNQ Formation of a massive "late-type", star-forming disk galaxy.
